Show AH150.4 - Mixer Amplifier
871099
Show AH150.4 Professional Class D, 4-channel amplifier with up to a total of 4 x 135W at 100V (RMS) and 100Hz - 15kHz (+0/-3dB) frequency response. This amplifier operates on both 70V RMS and 100V RMS, offering versatility in voltage options and making it suitable for various audio installations.
€799.00
Tax included
Show AH150.4 Professional Class D, 4-channel amplifier with up to a total of 4 x 135W at 100V (RMS) and 100Hz - 15kHz (+0/-3dB) frequency response. This amplifier operates on both 70V RMS and 100V RMS, offering versatility in voltage options and making it suitable for various audio installations. The amplifier supports both balanced (20kohm) and unbalanced (10kohm) inputs, allowing seamless integration with a wide range of audio sources and also slot in card for Dante (FSD-44D). The AH150.4 features efficient Switching Power Class D technology, ensuring minimal heat generation and higher energy efficiency.
Specifications
- Power: CHA-D /CH1-8 70V(RMS) 150W x 2, (ONE Channel Drive) 100V(RMS) 150W x 2, CHA-D/CH1-8 70V (RMS) 135W x 4, (All Channels Drive) 100V(RMS) 135W x 4
- Frequence response: 100Hz~15KHz(0+/-3dB)
- S/N rate: >95dB
- Input sensitivity: 0.9-1.1V (0+/-1 dBv)
- Input Impedance: 20kΩ balanced ή 10kΩ balanced
- Inputs: Euroblock
- Outputs: Euroblock
- Power supply: 110 - 120V / 220-240V 50~60Hz
- Rack: 1U
- Dimensions (WxDxH): 483 x 360 x 44mm
- Weight: 5.4kg
- Category
- Power Amplifier 100V
- Channels
- 4
- Amp Class
- Class D
- Signal to Noise Ratio
- > 95 dB
- Frequency Response
- 100Hz - 15kHz (+0/-1dB)
- Inputs
- Euroblock
- Outputs
- Euroblock
- Main Voltage
- AC: 110-120V or 220~240V 50/60Hz
- Rack Unit
- 1U
- Colour
- Black
- Width (mm)
- 483
- Height (mm)
- 44
- Depth (mm)
- 281
- Weight (kg)
- 5.4
- Warranty
- 2
- Condition
- New
- EAN
- 4712646004668
- MPN
- AH150.4
